Roof-top tents are becoming increasingly popular, but they must only be fitted to suitable vehicles with compatible roof bars. Before purchasing a tent, you need to check both your vehicle's roof mounting system and its permitted load capacity.
Minimum dynamic (driving) weight carrying capacity
Your vehicle and roof bars must each have a minimum dynamic (driving) load capacity of 75 kg.
- If your roof-top tent weighs 75 kg or less, both the vehicle and roof bars must be rated to carry at least 75 kg while driving.
- If your tent weighs more than 75 kg, both the vehicle and roof bars must have a dynamic load capacity equal to or greater than the tent's weight.
Always follow the vehicle and roof bar manufacturers' limits and fitting instructions.
Vehicle Roof Type suitablility
Some roof top tent brands will suggest that you only need to worry about static and dynamic load weights, with no concern about the type of roof bar fixing. We take a different view, and think that the type of roof bar fixing really does matter, an opinion shared by for example Thule and Yakima, premium brands in the car racks sector who supply both roof bars and roof top tents, and would not reduce their own sales potential without very good reason.
Vehicles with a Plain Roof / Clamp on system:
Identifying if you have a plain roof:
If your car doesn't have any obvious fitting system on the roof the bars clamp around the bodywork.
You MUST NOT fit a roof tent to a vehicle with a plain roof fixing system.
The risk of damage is too high, and flexing roof bars might also loosen the fitting kit clamps, especially if the roof bars are not correctly fitted.
If your vehicle has Raised Rails:
Identifying if you have raised rails:
Raised rails run from front to back and you can usually push your hand under them.
Some raised roof rails are too weak; they are OK if there are more than two legs (center supported), or a two leg system is supported at each end (side supported). See the examples below:
Centre supported
Side supported
Unsupported
Additionally, the cross bars must be positioned as close as possible to the side or centre rail legs.
Other vehicle roof types
All of the following roof types are suitable for roof tents, subject to the vehicle having a minimum dynamic (driving) weight carrying capacity of 75kg.
